Logitech Swytch

Logitech Swytch – Technical Specifications

Ports & Interfaces

Logitech Swytch Hub

• Power

• HDMI 2.0 (to display)

• HDMI 2.0 (to meeting room computer)

• USB 3.0 Type-A (to conference camera)

• USB 3.0 Type-C (to meeting room computer)

• USB 3.0 Type-C (to Swytch Extender)

Swytch Extender

• Power

• USB 3.0 Type-A (to Swytch Hub)

• USB 3.0 Type-C (to Swytch Connector)

• USB 3.0 Micro-B (to Swytch Connector)

Logitech Swytch Connector

• USB 3.0 Type-A (for laptops with Type-A ports)

• USB 3.0 Type-C (for laptops with Type-C ports)

Mounting Options

• Swytch Hub: Works with Logitech PC Mount (sold separately)

• Swytch Extender: Mount through a 25 mm grommet hole or under the table (hardware included)

• Swytch Connector: Includes magnetic dock

General Specifications

• Meeting room displays supported: 1

• Maximum display output: 4K @ 60 fps

• Maximum camera input: 4K @ 30 fps

• Laptop audio (local sharing): Yes

• Laptop audio (online meetings): Yes – supported on services with system audio sharing

• Device management: Remote monitoring & management with Logitech Sync

Compatibility

Conference Cameras

• Logitech Rally & Rally Plus

• Rally Bar & Rally Bar Mini

• MeetUp

• GROUP

• Other USB conference cameras

Room Solutions

• Microsoft Teams Rooms

• Zoom Rooms

With Swytch, you can deploy video conferencing room solutions from providers like Microsoft^® or Zoom^®, while also allowing people to use meeting rooms with other video services.
